| Brand Name: | YuHong |
| Model Number: | ASTM B111 C70600 Copper Nickle 90/10 Seamless Tube |
| MOQ: | 200~500 KGS |
| Price: | Negotiable |
| Payment Terms: | T/T, L/C AT SIGHT |
| Supply Ability: | According to Clients' requirements |
| Attribute | Value |
|---|---|
| Product Name | Copper Nickel 90/10 Seamless Tube |
| Tube Specification | ASTM B111 |
| Tube Material | C70600 |
| Tube's OD and WT | Customizable to Customer Requirements |
| Tube's End | Plain end |
| Tube Length | Customizable to Customer Requirements |
| Applications | Condensers and Heat Exchangers; Power Plant Condensers; Cooling Systems; Heat Transfer Equipment |
| General Test/Inspection | ET, HT, PMI, Flattening Test (as per customer requirements) |
| Element | Composition (% by Weight) |
|---|---|
| Copper (Cu) | Remainder (Balance) |
| Nickel (Ni) | 9.0 - 11.0 |
| Iron (Fe) | 1.0 - 1.8 |
| Manganese (Mn) | 0.5 - 1.0 |
| Lead (Pb) | 0.05 max |
| Zinc (Zn) | 1.0 max |
| Carbon (C) | 0.05 max |
| Phosphorus (P) | 0.02 max |
| Sulfur (S) | 0.02 max |
| Others (Total) | 0.5 max |
| Property | Annealed Condition | Hard-Drawn Condition |
|---|---|---|
| Tensile Strength (min) | 290 MPa (42 ksi) | 380 MPa (55 ksi) |
| Yield Strength (0.2% offset, min) | 125 MPa (18 ksi) | 275 MPa (40 ksi) |
| Elongation (min, % in 50mm) | 30% | 15% |
| Hardness (Rockwell B, max) | 65 HRB | 85 HRB |
