C70600 Copper Alloy Steel Heat Transfer Tube Stainless Steel For Condenser Coolers

Product Details:

Place of Origin:	China , Korea
Brand Name:	YUHONG
Certification:	ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number:	Seamless Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Delivery Time:	5 - 60 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Contact Now Chat Now

Detailed Product Description

Material:

C70600

Standard:

ASTM B466 , ASME SB466

Ends:

PE , BE

Application:

Heat Exchangers, Condensers, Coolers, Etc.

Highlight:

C70600 heat transfer tube

Copper Alloy heat transfer tube

C70600 stainless steel condenser tubes

C70600 Copper Alloy Steel Heat Transfer Tube Stainless Steel For Condenser Coolers

Product Specifications

Attribute	Value
Material	C70600
Standard	ASTM B466, ASME SB466
Ends	PE, BE
Application	Heat Exchangers, Condensers, Coolers, Etc.

Product Description

ASTM B466 specifies seamless copper-nickel alloy tubes for heat exchangers, condensers, and similar applications. The C70600 alloy meets rigorous requirements for mechanical properties, corrosion resistance, and heat transfer performance.

C70600 copper-nickel alloy tubes offer exceptional corrosion and biofouling resistance, ensuring long service life with minimal maintenance. Their superior thermal conductivity and mechanical strength enable efficient heat exchange in demanding environments, including high-pressure systems and extreme conditions like offshore platforms and marine applications.

Chemical Composition

Grade	Cu	Ni	Fe
ASTM B466 C70600	88.7-90.3%	9-11%	1-1.8% (for strength and corrosion resistance)

Mechanical Properties

Grade	Yield Strength	Tensile Strength	Elongation
ASTM B466 C70600	Approximately 105 MPa (15 ksi)	Approximately 275 MPa (40 ksi)	≥ 30%

Applications

Cooling Systems in Naval Vessels: Resists corrosion from saltwater in continuous marine operations.
Heat Exchanger Tubes for Nuclear Power: Performs reliably in high-pressure nuclear cooling systems.
Offshore Platform Cooling: Ideal for seawater cooling systems in oil rigs and gas platforms.
Chemical Plant Heat Exchangers: Withstands aggressive chemicals and high temperatures in industrial processes.
