HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number:	ASME SA213 T12

Payment & Shipping Terms:

Minimum Order Quantity:	Depend the size of finned tubes
Price:	20-10000 USD
Packaging Details:	Ply-wooden Case With Iron Frame
Delivery Time:	35-60 days
Payment Terms:	L/C, T/T
Supply Ability:	1000 tons/month

Contact Now Chat Now

Detailed Product Description

Product:	Finned Tube	Type:	HFW / Solid Finned Tubes
Tubes:	ASME SA213 T12	Fins:	TP304
Length:	According To Clients' Need	Size And Details:	According To Clients' Need
Packing:	Ply-wooden Case With Iron Frame	Use:	Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, Etc
Highlight:	HFW high fin tube , TP304 high fin tube , HFW aluminum fins for copper pipe

HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304

Product Specifications

Attribute	Value
Product	Finned Tube
Type	HFW / Solid Finned Tubes
Tubes	ASME SA213 T12
Fins	TP304
Length	Custom according to requirements
Size and details	Custom according to requirements
Packing	Ply-wooden Case With Iron Frame
Use	Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc

Product Description

Solid Welded Finned Tubes ASME SA213 Material T12 for Power Generation. ASME SA213/ASTM A213 covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes. T12 material offers high-temperature strength, excellent corrosion resistance, weldability and formability. These tubes are essential for high-temperature and high-pressure applications, providing durability and reliability in demanding environments.

Definition

Solid fin tubes, also called high frequency welded fin tubes, are specialized heat exchanger tubes with fins integrally bonded to the outer surface. These fins enhance heat transfer efficiency by increasing the surface area in contact with the surrounding medium.

Chemical Composition (%)

Grade	C	Mn	P	S	Si	Cr	Mo
T12	0.05-0.15	0.30-0.61	0.025	0.025	0.50	0.80-1.25	0.44-0.65

Mechanical Properties

Grade	Tensile Strength, min	Yield Strength (0.2% Offset, min)	Tempering Temperature, min
T12	60ksi (415 MPa)	32ksi (220 MPa)	1200-1350°F [650-730°C]

Additional Properties

T12 | Elongation in 2 in.: 30%
Hardness: 163HBW/170HV
Rockwell: 85HRB

Key Advantages

Increased surface area improves heat transfer efficiency
Enhanced corrosion and wear resistance with low contact thermal resistance
High stability and anti-ash ability with excellent stiffness and seismic performance
Superior weld microstructure due to high welding speed and strong self-cooling effect
Robust construction resistant to mechanical damage

Applications
