ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised

Product Details:

Place of Origin:	China,Korea
Brand Name:	YUHONG
Certification:	ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Model Number:	High Frequency weld fin tube, Welding fin tube, Fin Tube, Finned Tube, Solid Fin tube, HFW fin tube, Serrated Fin Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	1--10000 USD
Packaging Details:	Bundle + Cap , Ply wooden case
Delivery Time:	5---75 days
Payment Terms:	L/C, T/T
Supply Ability:	10000 tons/month

Contact Now Chat Now

Detailed Product Description

Base Tube Material:	T12	Standard:	ASME SA213 , ASTM A213
Fin Material:	Stainless Steel	Fin Type:	High Frequency Welding Serrated Fin Tube
Length:	Max.: 34m/pc	Application:	Fired Furnace, Fired Heater, Convection Tube, Radiant Tube, Raffinate, Tube Coil, Coils
Highlight:	ASME SA213 embedded fin , T12 embedded fin , T12 low fin tubes for heat exchangers

ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised

Product Specifications

Attribute	Value
Base Tube Material	T12
Standard	ASME SA213, ASTM A213
Fin Material	Stainless steel
Fin Type	High Frequency Welding Serrated Fin Tube
Length	Max.: 34m/pc
Application	Fired Furnace, Fired Heater, Convection Tube, Radiant Tube, Raffinate, Tube Coil, Coils

Product Description

The "T12" designation refers to Grade T12, a low-alloy steel containing 1.25% chromium and 0.5% molybdenum, offering excellent high-temperature strength.

Provides superior resistance to creep and oxidation, making it ideal for demanding power plant applications
Chromium and molybdenum content enhances corrosion resistance in high-temperature environments
Serrated fins increase surface area for optimal heat dissipation or absorption
High-frequency welding process ensures cost-effectiveness and production efficiency

Chemical Composition

Grade	Cr	Mo	C	Fe
ASME SA213 T12	0.8-1.25%	0.44-0.65%	0.05-0.15%	Balance

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness	Operating Temperature Range
ASME SA213 T12	415-585 MPa (60-85 ksi)	≥ 205 MPa (30 ksi)	≥ 24%	≤ 85 HRB	Up to 560°C (1040°F)

Applications

Heat Exchanger Units Boilers Waste Heat Recovery Flue Gas Desulfurization Superheaters & Reheaters Heat Transfer Systems Cooling Systems Steam Generators Desalination Plants Air Heaters Chilled Water Systems
