16ga HFW Serrated Helical Finned Tube Internally ASTM A335 P11 for Petrochemical

ASTM A335 P11 HFW Serrated Finned Tube With Gr.11 Fins For Power Plants

What is ASTM A335 P11 HFW Serrated Finned Tube With Gr.11 Fins?

ASTM A335 P11 HFW Serrated Finned Tube with Gr.11 Fins is a type of heat exchanger tube that is made of ASTM A335 P11 alloy steel with serrated fins made of Grade 11 alloy material. The serrated fins provide increased heat transfer efficiency by increasing the contact surface area between the fluid inside the tube and the surrounding medium. This type of finned tube is commonly used in industrial applications where high heat transfer rates are required.

What's the advantage of ASTM A335 P11 HFW Serrated Finned Tube With Gr.11 Fins?

• Increased heat transfer efficiency: The serrated fins increase the contact surface area between the fluid inside the tube and the surrounding medium, resulting in improved heat transfer efficiency.
• Higher thermal conductivity: The use of high-quality alloy materials in both the tube and fins ensures good thermal conductivity, which is crucial for effective heat transfer.
• Corrosion resistance: ASTM A335 P11 alloy steel is known for its corrosion resistance, making it suitable for applications where exposure to corrosive environments is a concern.
• Durable and long-lasting: These finned tubes are designed to withstand high temperatures and pressures, offering durability and long service life in industrial applications.
• Versatile applications: ASTM A335 P11 HFW Serrated Finned Tube with Gr.11 Fins can be used in a wide range of applications, including heat exchangers, boilers, and other industrial heating systems.

What's the Chemical Composition and Mechanical Properties of ASTM A335 P11?

Chemical Composition of ASTM A335 P11:

• Carbon: 0.05-0.15%
• Manganese: 0.30-0.60%
• Phosphorus: 0.025% max
• Sulfur: 0.025% max
• Silicon: 0.50-1.00%
• Chromium: 1.00-1.50%
• Molybdenum: 0.44-0.65%

Mechanical Properties of ASTM A335 P11:

• Tensile strength: 415 MPa min
• Yield strength: 205 MPa min
• Elongation: 30% min

These values represent typical chemical composition and mechanical properties for ASTM A335 P11 alloy steel. Actual properties may vary depending on manufacturing process and specific requirements.

What is the application of ASTM A335 P11 HFW Serrated Finned Tube With Gr.11 Fins?

ASTM A335 P11 HFW Serrated Finned Tubes with Gr.11 Fins are commonly used in various industrial applications where efficient heat transfer is required. Some of the typical applications include:

1. Heat Exchangers: These finned tubes are used in heat exchangers to transfer heat between two fluids efficiently. The increased surface area provided by the serrated fins enhances heat transfer rates.

2. Boilers: ASTM A335 P11 finned tubes are used in boiler systems to improve the heat transfer efficiency and enhance the overall performance of the boiler.

3. Waste Heat Recovery Systems: These finned tubes are often used in waste heat recovery systems to recover excess heat from industrial processes and convert it into useful energy.

4. Power Plants: Serrated finned tubes with Gr.11 fins are employed in power plants for various heat exchange applications, such as in steam generators and condensers.

5. Petrochemical Industry: These finned tubes find applications in the petrochemical industry for heat transfer in processes such as refining, distillation, and chemical production.

Overall, ASTM A335 P11 HFW Serrated Finned Tube with Gr.11 Fins is versatile and can be used in a wide range of applications where high-efficiency heat transfer is essential.
