EN10216-5 6mm Boiler Heat Exchanger Tube Bundle PMI Testing

Brand Name:	YUHONG
Model Number:	Seamless tube
MOQ:	1 PC
Price:	1 - 10000 USD
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

1.4541

Standard:

EN10216-5

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Packaging Details:

Ply-Wooden Case & Woven Bag

Supply Ability:

10000 Tons/Month

Highlight:

PMI Testing Heat Exchanger Tube

6mm Heat Exchanger Tube

EN10216-5 boiler tube bundle

Product Description

EN10216-5 6mm Boiler Heat Exchanger Tube Bundle PMI Testing

Product Specifications

Attribute	Value
Material	1.4541
Standard	EN10216-5
Ends	PE, BE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Description

The EN10216-5 1.4541 Stainless Steel Heat Exchanger Tube is engineered for high-temperature applications, delivering exceptional corrosion resistance and thermal stability. This austenitic stainless steel (equivalent to AISI 321) is titanium-stabilized to prevent carbide precipitation, making it ideal for demanding chemical processing environments.

Grade 1.4541 contains chromium (17-19%) and nickel (9-12%) with titanium additives for enhanced stability. It offers superior resistance to various corrosive conditions, particularly intergranular corrosion. Manufactured to EN10216-5 standards, these seamless pressure tubes meet rigorous quality requirements for safety and performance.

Chemical Composition

Grade	Cr	Ni	Ti	C
1.4541	17.0-19.0%	9.0-12.0%	≥ 5x C content	≤ 0.08%

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
1.4541	≥ 210 MPa (30 ksi)	≥ 520 MPa (75 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Key Features

Optimized Material Composition: Chromium (17-19%), nickel (9-12%), and titanium for enhanced stabilization
Superior Corrosion Resistance: Excellent resistance to intergranular corrosion, especially in welded applications
High-Temperature Performance: Maintains stability in elevated temperature environments
Exceptional Durability: Withstands thermal cycling and mechanical stress while maintaining structural integrity

Industrial Applications

Chemical Processing: Reactors, heat exchangers, and equipment handling corrosive chemicals
Oil & Gas: Offshore platforms, refineries, and petrochemical facilities for heat exchangers and piping
Power Generation: Heat exchangers in high-temperature, high-pressure power plant environments
Food & Beverage: Pasteurization and sterilization equipment requiring hygienic properties
Pharmaceuticals: Processes demanding high cleanliness standards and corrosion resistance
Marine Engineering: Components exposed to seawater and aggressive marine conditions
Aerospace: Aircraft components requiring oxidation resistance at elevated temperatures
