Boiler Tube
>
OEM Carbon Steel Boiler Tube Pipe ASME SA209 T1A For Superheater

OEM Carbon Steel Boiler Tube Pipe ASME SA209 T1A For Superheater

Brand Name: YUHONG
Model Number: Boiler Tube
MOQ: 1 PC
Price: 1 - 10000 USD
Payment Terms: L/C, T/T
Supply Ability: 10000 Tons/Month
Detail Information
Place of Origin:
China , Korea
Certification:
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Material Grade:
T1a
Standard:
ASTM A209 , ASME SA209
External Diameter:
>38.1
Ends:
PE , BE
Tube Material:
Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon
Application:
Boiler
Packaging Details:
Ply-Wooden Case + Iron Frame
Supply Ability:
10000 Tons/Month
Highlight:

Carbon Steel boiler tube pipe

,

OEM boiler tube pipe

,

ASME SA209 boiler superheater tubes

Product Description
OEM Carbon Steel Boiler Tube Pipe ASME SA209 T1A For Superheater
Product Specifications
Attribute Value
Material Grade T1a
Standard ASTM A209, ASME SA209
External Diameter >38.1
Ends PE, BE
Tube Material Nickel Alloy, Alloy, Stainless Steel, Duplex Stainless Steel, Carbon
Application Boiler
Product Overview
Carbon Steel ASME SA209 T1a Boiler Tube is engineered for superior performance in high-temperature environments, making it the ideal choice for power plant boilers and superheaters.

The chromium-enhanced composition provides exceptional oxidation resistance, ensuring long-term durability in demanding heat applications. These tubes maintain structural integrity under high-pressure conditions, making them perfect for steam generation systems and other pressurized industrial processes.

With excellent heat transfer properties, SA209 T1a tubes optimize efficiency in boilers, heat exchangers, and economizers, delivering reliable performance in critical industrial applications.

Chemical Composition
  • Carbon: 0.30% - 0.40%
  • Manganese: 0.60% - 0.90%
  • Phosphorus: ≤ 0.035%
  • Sulfur: ≤ 0.035%
  • Silicon: 0.20% - 0.40%
  • Copper: ≤ 0.35%
  • Chromium: 0.80% - 1.25%
  • Nickel: ≤ 0.50%
Mechanical Properties
  • Tensile Strength: 485 - 620 MPa (70 - 90 ksi)
  • Yield Strength: 275 MPa (40 ksi) min.
  • Elongation: 20% min. (in 8 inches)
  • Hardness: 170 HB (Brinell Hardness) max.
  • Impact Toughness: Designed for good toughness at elevated temperatures
Key Applications
Power Generation Plants: Essential for superheaters, reheaters, and boiler drums where high-temperature steam is generated, offering reliable performance under continuous thermal stress.
Heat Exchangers: Ideal for high-efficiency heat transfer systems due to superior thermal conductivity and structural strength.
Marine Boilers: Provides dependable performance in shipboard boiler systems, withstanding the unique challenges of marine environments.
Industrial Furnaces: Used in high-temperature furnaces and kilns where efficient heat transfer and mechanical durability are critical.
