ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants

ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants

  • ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants
  • ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants
  • ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants
  • ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants
ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants
Product Details:
Place of Origin: China , Korea
Brand Name: YUHONG
Certification: ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number: Boiler Tube
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: 1 - 10000 USD
Packaging Details: Ply-Wooden Case + Iron Frame
Delivery Time: 5 - 90 Days
Payment Terms: L/C,T/T
Supply Ability: 10000 Tons/Month
Contact Now Chat Now
Detailed Product Description
Material Grade: A335 P22 Standard: ASTM A335 , ASME SA335
External Diameter: >38.1 Ends: PE , BE
Tube Material: Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon Application: Boiler
Highlight:

A335 P22 boiler copper pipe

,

ODM boiler copper pipe

,

Seamless sa 179 tube

ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants
Product Description
Grade A335 P22 is a specification for seamless ferritic alloy-steel pipe designed for high-temperature service. These tubes are engineered for demanding applications involving high-pressure and high-temperature environments, particularly in power plants and petrochemical facilities.
ASTM A335 P22 seamless boiler tubes deliver exceptional performance in power generation, petrochemical processing, chemical plants, industrial boilers, oil and gas operations, and marine applications. Their superior resistance to high temperatures and corrosive environments ensures long-term reliability in the most challenging conditions.
Within petrochemical plants, A335 P22 pipes perform a core function, akin to "arteries," and are widely used in the construction of hydrocracking units, catalytic cracking units, ethylene cracking furnaces, and process piping for various fired heaters. These units operate under extremely severe conditions, where the pipes transport high-temperature, high-pressure, and sometimes corrosive hydrocarbon-hydrogen mixtures, steam, or other process fluids.
The alloy combination of approximately 2.25% Chromium (Cr) and 1% Molybdenum (Mo) in P22 material provides exceptional capabilities: Molybdenum (Mo) significantly enhances the pipe's elevated temperature strength and resistance to creep rupture, ensuring structural integrity under long-term stress; while Chromium (Cr) imparts superior resistance to oxidation and sulfidation corrosion, effectively protecting against degradation from high-temperature flue gases and certain corrosive media in the process environment. This greatly extends the equipment's service life and ensures the safety and continuity of the production process.
Chemical Composition
Grade C Mn P S Si Cr Mo
A335 P22 0.05-0.15% 0.30-0.60% ≤ 0.25% ≤ 0.25% 0.50% maximum 1.90-2.60% 0.87-1.13%
Mechanical Properties
Grade Tensile Strength Yield Strength Elongation Hardness
A335 P22 Minimum 415 MPa (60,200 psi) Minimum 205 MPa (30,000 psi) 20% minimum in 50 mm ≤ 220 HB (Brinell Hardness)
Key Features
  • High-Temperature Strength: Ensures reliable performance in high-temperature applications
  • Oxidation Resistance: Provides excellent resistance to oxidation in demanding environments
  • Creep Resistance: High resistance to creep for long-term reliability under continuous high-temperature exposure
  • Durability: High tensile strength and toughness provide extended service life in harsh conditions
  • Weldability: Good weldability allows for easy fabrication and repair of boiler tubes
  • Versatility: Suitable for diverse high-temperature and high-pressure applications across multiple industries
Applications
Petrochemical Industry: Refinery equipment, catalytic cracking units, and high-temperature heat exchangers in petrochemical plants.
Marine Applications: Marine boilers for steam generation, marine heat exchangers, and high-pressure steam systems in engine rooms.
Oil and Gas Industry: Offshore platform components, downhole tubing for extraction, and refinery equipment processing sour gas.
ASTM A335 P22 Seamless Ferritic Alloy Steel Pipe Fro Petrochemical Plants 0
