SMLS Stainless Steel Fin Boiler Tube Industries For Heat Exchangers ASTM A268 TP410

Product Details:

Place of Origin:	China, Korea
Brand Name:	YUHONG
Certification:	ASME, ASTM, ABS, DNV-GL, LR, BV, CCS, KR, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number:	Boiler Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	10-1000 USD/PC
Packaging Details:	Ply-Wooden Case & Woven Bag
Delivery Time:	10-90 DAYS
Payment Terms:	T/T,L/C
Supply Ability:	10000 TONS PER MONTH

Contact Now Chat Now

Detailed Product Description

Standards:

ASTM A268 , ASME SA268

Materials:

TP410

Ends:

PE, BE

Application:

Heat Exchangers , Boilers , Condensers

Highlight:

SMLS boiler tube industries

A268 boiler tube industries

A268 boiler fin tube

SMLS Stainless Steel Fin Boiler Tube Industries For Heat Exchangers ASTM A268 TP410

Product Specifications

Attribute	Value
Standards	ASTM A268, ASME SA268
Materials	TP410
Ends	PE, BE
Application	Heat Exchangers, Boilers, Condensers

Product Overview

The ASTM A268 TP410 Seamless Stainless Steel Tube is a high-strength ferritic stainless steel product manufactured under the ASTM A268 standard. This specification covers seamless and welded tubes designed for high-temperature and corrosion-resistant applications. TP410, a martensitic stainless steel grade, is particularly known for its excellent mechanical properties, good corrosion resistance, and high heat resistance.

Key Features and Benefits

High Strength and Hardness: As a martensitic stainless steel, TP410 offers superior tensile strength and wear resistance, making it suitable for demanding applications.
Good Corrosion Resistance: TP410 provides moderate resistance to corrosion in mild environments, particularly in conditions with low moisture and chemical exposure.
Heat Resistance: This material performs well in high-temperature environments, which is ideal for applications like heat exchangers and boiler systems.
Seamless Manufacturing: The seamless construction ensures uniformity, high pressure tolerance, and excellent dimensional accuracy.

Chemical Composition

Grade	Cr	Mn	Ni	Si
ASME SA179	11.5 - 13.5	≤ 1.00	≤ 0.75	≤ 1.00

Mechanical Properties

Grade	Yield Strength	Tensile Strength	Elongation (in 2")
ASME SA179	≥ 205 MPa (30,000 psi)	≥ 415 MPa (60,000 psi)	≥ 20%

Applications

Heat Exchangers: Ideal for transferring heat in high-temperature environments.
Boiler Tubes: Suitable for high-pressure and high-temperature boiler systems.
Chemical Processing Equipment: Used in process piping and equipment due to its resistance to corrosion and wear.
Petrochemical Industry: Common in oil and gas applications requiring strength and durability.
Pulp and Paper Industry: Used in environments where moderate corrosion resistance is required.
