OEM Longitudinal Crimped Finned Aluminum Tubing API Certificated

Product Details:

Place of Origin:	China , Korea
Brand Name:	YUHONG
Certification:	ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Model Number:	Longitudinal Finned Tube , Longitudinal Welding Fin tube

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Bundle + Cap , Ply wooden case
Delivery Time:	5 - 75 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Contact Now Chat Now

Detailed Product Description

Base Tube Material:

TP316L, TP304L, TP309S, TP310H

Fin Type:

Longitudinal Finned Tube , Longitudinal Welding Fin Tube

Fin Qty:

..., 16U , 18U, 20U, 22U ,...

Fin Tube Length:

20m/pc

Highlight:

OEM finned aluminum tubing

API certificated finned aluminum tubing

Longitudinal crimped fin tube

OEM Longitudinal Crimped Finned Aluminum Tubing API Certificated

Product Specifications

Attribute	Value
Base Tube Material	TP316L, TP304L, TP309S, TP310H
Fin Type	Longitudinal Finned Tube, Longitudinal Welding Fin tube
Fin Quantity	..., 16U, 18U, 20U, 22U,...
Fin Tube Length	20m/pc

ASTM A213 TP316L Base Tube Composition

Grade	UNS Designation	C	M	P	S	Si	Cr	Ni	Mo	N	Nb	Ti	Other
TP316L	S31603	0.035	2	0.045	0.03	1	16.0-18.0	10.0-14.0	2.00-3.00	...	...	...	...

A213 TP316L Longitudinal Welding Fin Tube Strength

Structural Integrity: The longitudinal welding process creates a strong bond between fins and tube, enhancing overall structural integrity and preventing weaknesses under pressure or thermal stress.
Weld Quality: High-quality welds prevent stress concentrations, with non-destructive testing methods ensuring weld integrity.
Thermal Expansion: Design accommodates thermal movement to prevent stress buildup.
Pressure Resistance: Engineered to withstand significant internal and external pressures.
Fatigue Resistance: Designed for durability under repeated thermal cycling.
Corrosion Resistance: Materials and coatings enhance longevity in corrosive environments.

Applications in Oil Coolers and Refrigeration Systems

Our professional-grade longitudinal finned tubes are engineered to maximize heat exchange efficiency in industrial applications. The design features cylindrical tube bodies with uniformly welded fins along their length, creating increased surface area for optimal heat transfer. Fluid flows through the tube while exchanging heat with external air or fluid, with the longitudinal fin arrangement reducing flow resistance and eliminating dead zones for superior performance.
