Seamless Integral Low Fin Tubes finned Heating pipe JIS G3461 Standard OEM

Product Details:

Place of Origin:	China , Korea
Brand Name:	YUHONG
Certification:	ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number:	ASTM A179

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply - Wooden Case + Iron Frame
Delivery Time:	5 - 90 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Contact Now Chat Now

Detailed Product Description

Material Grade:	A179	Material Standard:	ASTM A179,ASME SA179,JIS G3461,
Type:	Low Fin Type	Application:	Heat Exchangers, Condensers, Coolers
Fin Material:	Carbon
Highlight:	JIS G3461 Integral Low Fin Tubes , OEM Integral Low Fin Tubes , OEM finned heating pipe

Seamless Integral Low Fin Tubes - JIS G3461 Standard OEM

Product Specifications

Material Grade	A179
Material Standard	ASTM A179, ASME SA179, JIS G3461
Type	Low Fin Type
Application	Heat Exchangers, Condensers, Coolers
Fin Material	Carbon

Product Description

Low finned tubes expand the heat transfer area by adding ribs outside the tube. Compared with light tubes, they provide a larger surface area while using the same metal material, significantly improving the heat transfer coefficient.

The increased heat transfer area per unit volume reduces the number of tubes required for finned tube heat exchangers under identical heat loads, allowing for smaller shell diameters or heights and substantial space savings.

Chemical Composition

Grade	C	P	Mn	S
A179	0.06~0.18	≤0.035	0.27~0.63	≤0.035

Fin Tube Types

Type	Description	Base tube O.D. (mm)	Fin pitch	Fin height	Fin thick
Embedded	G-type fin tube	16-63	2.1~5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6~10	<17	0.2-0.4
Low fin tube	T-type fin tube	10-38	0.6~2	<1.6	~0.3
Bamboo tube	Corrugated tube	16-51	8.0~30	<2.5	/

Applications

Air Conditioning Systems
Refrigeration Equipment
Boilers
Heat Exchangers
Automotive Radiators

Advantages

Improved Heat Exchange Efficiency
Space Saving Design
Reduced Energy Consumption
Strong Adaptability
Corrosion Resistance
Easy Maintenance
