Straight Copper Nickel Low 3/4" Finned Copper Tubing For Heat Exchangers C71500

Product Details:

Place of Origin:	China , Korea
Brand Name:	YUHONG
Certification:	ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number:	Low Fin Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Delivery Time:	5 - 90 Days
Supply Ability:	10000 Tons/Month

Contact Now Chat Now

Detailed Product Description

Bast Tube Material Grade:	UNS C71500 , Cu-Ni 70/30	Bast Tube Material Standard:	ASTM B111 , ASME SB111
Type:	Straight Tube	Application:	Heat Exchangers, Condensers, Coolers, Etc.
Fin Type:	Low Fin	Fin Material:	Copper
Highlight:	Copper Nickel 3 4 finned copper tubing , C71500 3 4 finned copper tubing , C71500 low fin tubes for heat exchangers

Straight Copper Nickel Low 3/4" Finned Copper Tubing For Heat Exchangers C71500

Product Specifications

Attribute	Value
Base Tube Material Grade	UNS C71500, Cu-Ni 70/30
Base Tube Material Standard	ASTM B111, ASME SB111
Type	Straight Tube
Application	Heat Exchangers, Condensers, Coolers, Etc.
Fin type	Low Fin
Fin Material	Copper

Product Description

Low fin tubes fabricated from ASTM B111 C71500 (Copper Nickel Alloy 70/30) are exceptionally well-suited for high-performance heat exchangers, particularly in marine, desalination, and power plant applications. The combination of enhanced heat transfer efficiency and remarkable resistance to corrosion makes these tubes a preferred choice in demanding environments.

Material Characteristics

This specification covers seamless copper-nickel alloy tubes. The C71500 alloy, also known as Copper Nickel 70/30, comprises 70% copper and 30% nickel, providing excellent resistance to seawater corrosion, biofouling, and erosion. The alloy also contains small amounts of iron and manganese to enhance overall strength and corrosion resistance.

Low Fins

The fins are integrally formed from the base tube material through a precise rolling or extrusion process, increasing the external surface area for better heat transfer. These integral fins ensure a strong bond with no risk of detachment.

Key Features

Enhanced Heat Transfer: Increased surface area and improved thermal performance through fin design.

Corrosion Resistance: Superior seawater, biofouling, and erosion resistance.

Mechanical Robustness: High strength and durability for demanding applications.

Versatility: Suitable for various heat exchanger configurations in multiple industries.

Compact Design: Space-saving and cost-effective solution.

Applications

Marine Industry Desalination Plants Power Generation Chemical Processing HVAC and Refrigeration

Technical Specifications

Chemical Composition

Elements	Cu(1,2)	Pb	Zn	Fe	Ni(3)	Mn
Min (%)				0.40	29.0
Max (%)	Rem	0.05	1.0	1.0	33.0	1.0

(1) Cu + Sum of Named Elements 99.5% min. (2) Cu value includes Ag. (3) Ni value includes Co.
