Industrial Low Aluminum Electric Fin Tube ASTM A179 For Copper Pipe ODM

Product Details:

Place of Origin:	China , Korea
Brand Name:	YUHONG
Certification:	ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number:	Low Fin Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Delivery Time:	5 - 90 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Contact Now Chat Now

Detailed Product Description

Base Tube Material Grade:	ASTM A179, ASME SA179	Base Tube Material Standard:	A179
Type:	Straight Tube, U Tube	Application:	Heat Exchanger, Condenser
Fin Type:	Carbon Steel,Stainless Steel,Copper Alloy,Alloy Steel	Fin Material:	Aluminum , Copper , Stainless Steel , Carbon Steel
Highlight:	industrial electric fin tube , ODM electric fin tube , ODM aluminum fins for copper pipe

Industrial Low Aluminum Electric Fin Tube ASTM A179 For Copper Pipe ODM

Product Overview

Low fin tubes with a base tube made of ASTM A179 are highly efficient and durable components for heat exchangers, condensers, and evaporators. Their enhanced heat transfer properties, combined with the durability of ASTM A179 low-carbon steel, make them ideal for demanding industrial applications.

Key Specifications

Attribute	Value
Base Tube Material Grade	ASTM A179, ASME SA179
Base Tube Material Standard	A179
Type	Straight Tube, U Tube
Application	Heat Exchanger, Condenser
Fin Material Options	Aluminum, Copper, Stainless Steel, Carbon Steel

Technical Parameters

Parameter	Value
Tube OD	12.7~31.75 (mm)
Tube Wall Thickness	1.65~3.0 (mm)
Tube Length	≤18,500 (mm)
Fin Thickness	0.3~0.5 (mm)
Fin Height	0.9~1.3 (mm)
Fin Pitch	16~30 FPI

Key Features

High Heat Transfer Efficiency

Durable ASTM A179 Material

Integral Fin Construction

Compact Design

Anti-Corrosion

Anti-Wear

High Stability

Anti-Fouling

Material Composition (ASTM A179)

Element	Content (%)
Carbon (C)	0.06-0.18
Silicon (Si)	≤ 0.25
Manganese (Mn)	0.27-0.63
Phosphorus (P)	≤0.035
Sulfur (S)	≤0.035

Mechanical Properties

Property	Value
Tensile Strength	≥325 MPa
Yield Strength	≥180 MPa
Elongation	≥35%
Hardness (HRB)	≤72

Industrial Applications

Oil Refinery equipment
Petrochemical Plants
Condensers and Heat Exchangers
Power Plant Evaporators
Power Generation systems
HVAC and Air Conditioning
Refrigeration Manufacturing
Sea Water Desalination plants
Pharmaceutical Equipment
Pulp and Paper Industry

These low fin tubes provide a compact, cost-effective solution for improving heat transfer efficiency in demanding industrial environments while maintaining durability and corrosion resistance.
