ODM Stainless Steel Longitudinal Finned Tube Heating Pipe ASTM A213 TP316L

Product Details:

Place of Origin:	China , Korea
Brand Name:	YUHONG
Certification:	ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Model Number:	ASTM A213 TP316L

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply - Wooden Case + Iron Frame
Delivery Time:	5 - 90 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000 Tons/Month

Contact Now Chat Now

Detailed Product Description

Base Tube Material Grade:

TP304, TP304L, TP304H, TP310, TP310H, TP316L, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H,

Fin Material:

Carbon Steel , Stainless Steel , Alloy Steel

Type:

Longitudinal Finned Tube

Application::

Furnace Tube, Tube Coil , Radiate Tube , Convenction Tube , Fired Heater

Highlight:

ODM Longitudinal Finned Tube

Heating Longitudinal Finned Tube

ODM finned heating pipe

ODM Stainless Steel Longitudinal Finned Tube Heating Pipe ASTM A213 TP316L

Product Specifications

Base Tube Material Grade	TP304, TP304L, TP304H, TP310, TP310H, TP316L, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H
Fin Material	Carbon Steel, Stainless Steel, Alloy Steel
Type	Longitudinal Finned Tube
Application	Furnace Tube, Tube Coil, Radiate Tube, Convenction Tube, Fired Heater

Product Description

High Frequency Welding (HFW) Fin Tubes are engineered for superior heat transfer efficiency and durability across multiple industrial applications. Their robust construction withstands high temperatures and pressures while offering excellent corrosion resistance.

Fin Tube Types

Type	Description	Base Tube O.D. (mm)	Fin Pitch	Fin Height	Fin Thickness
Embedded	G-type fin tube	16-63	2.1~5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6~10	<17	0.2-0.4
Low fin tube	T-type fin tube	10-38	0.6~2	<1.6	~0.3
Bamboo tube	Corrugated tube	16-51	8.0~30	<2.5	/
Wound	L/KL/LL type fin tube	16-63	2.1~5	<17	~0.4
String	String fin tube	25-38	2.1-3.5	<20	0.2-0.5
U-type	U-type tube	16-38	/	/	/
Welding	HF-welding fin tube	16-219	3~25	5~30	0.8-3

Chemical Composition (ASTM A213 TP316L)

C	Si	Mn	P	S	Cr	Ni	Mo
≤ 0.035	≤ 0.75	≤ 2.0	≤ 0.040	≤ 0.03	16.0~18.0	10.0~15.0	/

Industrial Applications

Heat Exchangers
Chemical Industry
Refrigeration and Air Conditioning
Oil and Gas
Power Industry
Marine Engineering
Food and Pharmaceutical Industries
